Akuvox S539
Akuvox S539
Sektörün İlk Metaverse Android Kapı Telefonu
Teraslı bir yüzeye, çok işlevli bir kamera modülüne ve 15'in üzerinde erişim kontrol yöntemine sahip Akuvox S539 görüntülü kapı telefonu, bir avatarla yenilikçi bir şekilde oluşturulmuştur. Daha kullanışlı, daha güvenli ve daha etkileşimli. Metaverse-Intercom dönemi S539 ile geliyor.
Physical & Power
- Front Panel: Aluminum
- Display: 10 Inch IPS LCD
- Main Camera: 5M pixels, with starlight
- Light Sensor: Support
- Motion Sensor: Support
- ToF Sensor: Support
- Wiegand Port: Support
- RS485 Port: Support
- Line Out: Support
- RF Card Reader: 13.56MHz & 125kHz
- Relays Out: 3
- Inputs: 3
- Microphone: 2
- Speaker: 2
- Reset Button: 1
- Ethernet port: 1xRJ45, 10/100Mbps adaptive
- IEEE 802.3at PoE+
- Power: DC12V / 3A or DC24V / 1.5A
- IP & IK Level: IP66 & IK08
- Installation: Flush-mounted & Wall-mounted
- Flush-mounted DIM: 363.5x179.8x64mm
- Wall-mounted DIM: 367.5x183x35.5mm
- Working Humidity: 10~90%
- Working Temperature: -30°C ~ +55°C
- Storage Temperature: -30°C ~ +70°C
Audio
- SIP v1 (RFC2543), SIP v2 (RFC3261)
- Narrowband audio codec: G.711a, G.711μ, G.729
- Wideband audio codec: G.722
- DTMF: In-band, out-of-band DTMF (RFC2833), SIP Info
- Echo Cancellation
- Voice Activation Detection
- Comfort Noise Generator
Video
- Sensor: 1/2.7”, CMOS for main camera
- Pixels: CIF, QCIF, VGA, 4CIF, 720p, 1080p
- Video codec: H.264
- Video technology: HDR
- Video resolution: up to 1920x1080p
- Max. image transfer rate: 1080p – 30fps
- Viewing angle: 120°(H) / 72°(V)
- Compatible to 3rd-Party-Video components,
- e.g. NVRs
Networking & Protocol
- Protocols support: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Door Entry Feature
- Android OS for any 3rd party software or customization
- Relays controlled individually by DTMF tones
- Multi-way Unlock: Face, Card, PIN, BLE & QR code
- Camera permanently operational
- Auto-night mode with LED illumination
- White balance: auto
- Minimum illumination: 0.1LUX
Deployment & Maintenance
- Auto-Provisioning
- Web management portal
- Web-based packet dump
- Configuration backup / restore
- Entry log export
- Access table export / import
- Firmware upgrade
- System logs (include door access logs)
Application Scenario
- Provides resident / visitor access control for buildings such as condominiums, apartment buildings, office buildings, gated communities and industrial buildings
